Description
| Product Name: | Rechargeable 48v 100ah Battery | Battery Type: | LiFePO4 |
|---|---|---|---|
| Cycle Life: | 3000cycle/6000cycle | Protection: | Built-in Smart BMS |
| Capacity: | 50Ah/80ah/100Ah/200Ah | Application: | Solar, Wind, UPS Energy Storage |
| Communication Port: | RS232, RS485, CAN | ||
| High Light: | Lifepo4 48v 100ah Battery,
48v 100ah Battery Module Pack, Solar Energy System Battery Lifepo4 |
||
Product Description
Dyness 48v Battery Lifepo4 10kwh 6000 Times Cycle Life Lifepo4 Module Battery Pack With 10 Years Warranty
Product Features
Energy Cell 25N/37N/50N
Pylontech develop the energy type cells with our own unit design to ensure the high energy density with long cycle life the high
safety standard. Our cell had been widely deployed in the energy storage system, UPS system, logistic vehicles and other areas.
safety standard. Our cell had been widely deployed in the energy storage system, UPS system, logistic vehicles and other areas.
Product Performance
1.Compact size for saving space;
2.90% DOD with more useable capacity;
3.10+ years technical proven;
4.Be expandable for need;
5.Superior low failure rate;
6.Optimal electricity cost;
2.90% DOD with more useable capacity;
3.10+ years technical proven;
4.Be expandable for need;
5.Superior low failure rate;
6.Optimal electricity cost;
Components Included
1.Pylontech battery bracket;
2.Power cable,connection cables,parallel cable
3.Battery breaker;
4.BMS built in the battery.
LV-HUB Parallel Kit
Multi Battery Piles RS485 Communication Cable Connection Each Communication HUB connects maximum 5 battery string.
Each battery pile can configue maximum 8pcs US2000B Plus or 8 pcs US3000.
Specification
|
Basic Parameters
|
US2000C
|
Phantom-S
|
US3000C
|
|
Nominal Voltage (V)
|
48
|
48
|
48
|
|
Nominal Capacity (Wh)
|
2400
|
2400
|
3552
|
|
Usable Capacity (Wh)
|
2200
|
2200
|
3200
|
|
Dimension (mm)
|
442*410*89
|
440*440*88.5
|
442*420*132
|
|
Weight (Kg)
|
24
|
24
|
32
|
|
Discharge Voltage (V)
|
45 ~ 53.5
|
45 ~ 53.5
|
45-53.5
|
|
Charge Voltage (V)
|
52.5 ~ 53.5
|
52.5-53.5
|
52.5-53.5
|
|
Charge / Discharge Current (A) |
25(Recommend)
|
25(Recommend)
|
37 (Recommend)
|
|
50 (Max)
|
50 (Max)
|
74 (Max)
|
|
|
100 (Peak© 15s)
|
100 (Peak© 15s)
|
100 (Peak@15s)
|
|
|
Communication Port
|
RS485, CAN
|
RS485. CAN
|
RS485. CAN
|
|
Single string quantity(pcs)
|
16
|
8
|
16
|
|
Working Temperature/”C
|
-20~60
|
-20-60
|
-20-60
|
|
Shelf Temperature/°C
|
-20-60
|
-20 〜60
|
-20-60
|
|
Humidity
|
5%~85%
|
5%~85%
|
5%~85%
|
|
Altitude (m)
|
<4000
|
<4000
|
<4000
|
|
Design life
|
15+Years (25°C/77°F)
|
15+Years (25°C/77T)
|
15+Years (25aC/77T)
|
|
Cycle Life
|
>6000, 25C
|
>6000, 25 C
|
>6000, 25C
|
|
Authentication Level
|
UL/IEC62619/CE/UN38.3
|
IEC62619/CE /UN38.3
|
IEC62619/CE /UN38.3
|
Packing
Project Case
