Description
| Technical specification | ESSC0500A-1106 |
| DC data | |
| Battery capacity (MWh) | 1,106 |
| Number of battery racks | 8 |
| BMS communication interface | RS485/CAN |
| DC voltage range (V) | 600~850 |
| AC data | |
| Rated AC power(kW) | 500 |
| Max. AC power(kW) | 550 |
| Rated AC current(A) | 722 |
| Max. AC current(A) | 800 |
| DC current component | ＜0.5% |
| THDi | ＜3% (Rated power) |
| Rated grid voltage(V) | 400 |
| Allowable grid voltage range(V) | 320~460 |
| Rated grid frequency(Hz) | 50/60 |
| Allowable grid frequency range | 45~55/55~65 |
| Power factor | 1lagging-1leading |
| Isolation method | No isolation |
| General data | |
| Ingress protection | IP54 |
| Fire extinguishing system | support |
| Running time (full power) | 2h |
| Operating temperature | -30℃～ 55℃ |
| Dimension W*D*H (mm) | 12,192*2,438*2,896 |
| Weight (T) | 3.5 |
| BMS communication | RS485, CAN |
| EMS communication | RS485, TCP/IP |
| PCS cooling way | Temperature control intelligent air cooling |
| Battery cooling way | Air conditioning cooling |
| Altitude | 4,500m(>3,000 Derating) |
| Relative humidity | 0 ~95% non-condensing |
