| Technical specification |
|
|
|
|
| DC data |
|
|
|
|
| Battery capacity (kWh) |
|
|
100~200 |
|
| Number of battery racks |
|
|
1~2 |
|
| BMS communication interface |
|
RS485/CAN |
|
| DC voltage range(V) |
|
|
420~850 |
|
| AC data |
|
|
|
|
| Rated AC power(kW) |
|
|
30~150 |
|
| Max. AC power(kW) |
|
|
30~150 |
|
| Rated AC current(A) |
|
|
43~216 |
|
| Max. AC current(A) |
|
|
48~238 |
|
| DC current component |
|
|
＜0.5% |
|
| THDi |
|
|
＜3% (Rated power) |
|
| Rated grid voltage(V) |
|
|
400 |
|
| Allowable grid voltage range(V) |
|
320~460 |
|
| Rated grid frequency(Hz) |
|
|
50/60 |
|
| Allowable grid frequency range(Hz) |
|
45~55/55~65 |
|
| Power factor |
|
|
1lagging-1leading |
|
| Isolation method |
|
|
With the isolation |
|
| General Data |
|
|
|
|
| Ingress protection |
|
|
IP54 |
|
| Fire extinguishing system |
|
|
Support |
|
| Operating temperature |
|
|
-30℃～ 55℃ |
|
| Dimension W*D*H (mm) |
|
Customization*1,300*2,400 |
|
| Weight (kg) |
|
|
Customization |
|
| BMS communication mode |
|
|
CAN, RS485 |
|
| EMS communication mode |
|
|
RS485, TCP/IP |
|
| PCS cooling way |
|
Temperature control intelligent air cooling |
|
| Battery cooling way |
|
|
Air conditioning cooling |
|
| Altitude |
|
|
4,500m (>3,000 Derating) |
|
